Lamp-Tail/Stop/Turn-Left C4 (D4578D)

Harness-Family: Liftgate

Color: GREEN

Gender: FEMALE

Part Number: 13590276

Part Description: GT FBT 150 CONNECTOR ASSEMBLY

Connector No: D4578D

Option: Standard

Repair Kit Part Number: 68057313AA

Cavity Count: 3

Fig 1: Lamp-Tail/Stop/Turn-Left C4 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Tail/Stop/Turn-Left C4 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L15

WT/TN

LEFT BACKUP LAMP DRIVER

N/A

Z923

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
