Lamp-Tail/Stop/Turn-Left C1 (D4578A)

Harness-Family: Liftgate

Color: BLACK

Gender: FEMALE

Part Number: 15491547

Part Description: Not Available

Connector No: D4578A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Lamp-Tail/Stop/Turn-Left C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Tail/Stop/Turn-Left C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L71

WT/GY

LEFT REAR PARK LAMP DRIVER

N/A

Z923

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
