Lamp-Side Repeater-Right (D4576A)

Harness-Family: HDLP_Dash

Color: GRAY

Gender: FEMALE

Part Number: 15419715

Part Description: GT 150 SEALED Female CONNECTOR ASSEMBLY

Connector No: D4576A

Option: Standard

Repair Kit Part Number: 68052577AA

Cavity Count: 2

Fig 1: Lamp-Side Repeater-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Side Repeater-Right Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L162

WT/BR

RIGHT SIDE REPEATER LAMP CONTROL OUTPUT

N/A

Z904

GROUND

N/A

L162

WT/BR

RIGHT SIDE REPEATER LAMP CONTROL OUTPUT

N/A

Z904

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
