Lamp-PRNDL (D4561A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 174921-1

Part Description: 070 SERIES MULTILOCK CONNECTOR PLUG HSG

Connector No: D4561A

Option: Standard

Repair Kit Part Number: 68040489AA

Cavity Count: 3

Fig 1: Lamp-PRNDL Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-PRNDL Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

E12

OR/GY

PANEL LAMPS DRIVER

N/A

Z908

BK/PK

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
