Lamp-License-Left (D4545AS)

Harness-Family: Liftgate

Color: BLACK

Gender: MALE

Part Number: 12047663

Part Description: Not Available

Connector No: D4545AS

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Lamp-License-Left Connector End View

GCWD1016799

Courtesy of CHRYSLER

Fig 2: Lamp-License-Left Component Location

GCWD1187991

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

A

L3

WT/DB

20

LICENSE PLATE LAMP DRIVER

N/A

B

Z911

BK/LB

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
