Lamp-Fog-Right Front (D4532A)

Harness-Family: Front_End_Lighting

Color: RUST

Gender: FEMALE

Part Number: 13547918

Part Description: TAXI ASM CONN F GT FBT 150 SLD

Connector No: D4532A

Option: Standard

Repair Kit Part Number: 68087933AA

Cavity Count: 2

Fig 1: Lamp-Fog-Right Front Connector End View

GCWD1025375

Courtesy of CHRYSLER

Fig 2: Lamp-Fog-Right Front Component Location

GCWD1188267

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

B

L90

WT/OR

20

RIGHT FRONT FOG LAMP CONTROL

N/A

A

Z904

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
