Lamp-Center High Mounted Stop (D4509A)

Harness-Family: Liftgate

Color: BLACK

Gender: FEMALE

Part Number: 12052832

Part Description: INS

Connector No: D4509A

Option: Standard

Repair Kit Part Number: 68272974AA

Cavity Count: 2

Fig 1: Lamp-Center High Mounted Stop Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Center High Mounted Stop Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L51

WT/DG

BRAKE LAMP SWITCH OUTPUT

N/A

Z911

BK/LB

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
