Lamp-CUPHOLDER - Front (D2326A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 13648215

Part Description: 040-III CONNECTOR ASSEMBLY

Connector No: D2326A

Option: Standard

Repair Kit Part Number: 68272979AA

Cavity Count: 2

Fig 1: Lamp-Cupholder - Front Connector End View

GCWD1086589

Courtesy of CHRYSLER

Fig 2: Lamp-Cupholder - Front Component Location

GCWD1188390

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z908

BK/PK

20

GROUND

N/A

2

E12

OR/GY

20

PANEL LAMPS DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
