Lamp-Assembly-Right Front C3 (D6606C)

Harness-Family: Front_End_Lighting

Color: BLACK

Gender: FEMALE

Part Number: 13511134

Part Description: GT 150 3P SEALED CONNECTOR ASSEMBLY

Connector No: D6606C

Option: Standard

Repair Kit Part Number: 68057317AA

Cavity Count: 3

Fig 1: Lamp-Assembly-Right Front C3 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Right Front C3 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z904

GROUND

N/A

L78

WT/OR

RIGHT FRONT PARK LAMP DRIVER

EXCEPT EXPORT

L60

WT/TN

RIGHT FRONT TURN LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
