Lamp-Assembly-Left Front C4 (Except Export) (D6605D)

Harness-Family: Front_End_Lighting

Color: GRAY

Gender: FEMALE

Part Number: 15419715

Part Description: GT 150 SEALED Female CONNECTOR ASSEMBLY

Connector No: D6605D

Option: EXCEPT EXPORT

Repair Kit Part Number: 68052577AA

Cavity Count: 2

Fig 1: Lamp-Assembly-Left Front C4 Connector End View (Except Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C4 Component Location (Except Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L77

WT/BR

LEFT FRONT PARK LAMP DRIVER

N/A

Z901

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
