Lamp-Assembly-Left Front C3 (D6605C)

Harness-Family: Front_End_Lighting

Color: BLACK

Gender: FEMALE

Part Number: 13511134

Part Description: GT 150 3P SEALED CONNECTOR ASSEMBLY

Connector No: D6605C

Option: Standard

Repair Kit Part Number: 68057317AA

Cavity Count: 3

Fig 1: Lamp-Assembly-Left Front C3 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C3 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z901

GROUND

N/A

L77

WT/BR

LEFT FRONT PARK LAMP DRIVER

EXCEPT EXPORT

L61

WT/LG

LEFT FRONT TURN LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
