Lamp-Assembly-Left Front C1 (Except Export) (D6605A)

Harness-Family: Front_End_Lighting

Color: GRAY

Gender: FEMALE

Part Number: 12059181

Part Description: CONNECTOR ASSEMBLY M/P 280

Connector No: D6605A

Option: EXCEPT EXPORT

Repair Kit Part Number: 05102409AA

Cavity Count: 2

Fig 1: Lamp-Assembly-Left Front C1 Connector End View (Except Export)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Left Front C1 Component Location (Except Export)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L43

WT/DB

LEFT LOW BEAM DRIVER

N/A

Z901

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
