Lamp-Assembly Tail-Right C3 (D6642C)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13511134

Part Description: GT 150 3P SEALED CONNECTOR ASSEMBLY

Connector No: D6642C

Option: Standard

Repair Kit Part Number: 68057317AA

Cavity Count: 3

Fig 1: Lamp-Assembly Tail-Right C3 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly Tail-Right C3 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z914

BK/OR

GROUND

N/A

L72

WT/OR

RIGHT REAR PARK LAMP DRIVER

N/A

L54

WT/LG

RIGHT STOP LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
