Lamp-Assembly Tail-Right C2 (D6642B)

Harness-Family: Body

Color:

Gender: MALE

Part Number: Yellow-3

Part Description: Not Available

Connector No: D6642B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Lamp-Assembly Tail-Right C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z914

BK/OR

GROUND

N/A

L62

WT/YL

RIGHT REAR TURN LAMP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
