With Paddle Shift

REMOTE RADIO SWITCH WITH PADDLE SHIFT





The remote radio switches are mounted to the back of the steering wheel. Each switch consists of a remote radio switch and a paddle shift switch.

The right switch (1) consists of the following functions:

- Upshift switch (paddle shift) (10)
- Volume "UP" (9)
- Mode (8)
- Volume "DOWN" (7)

The left switch (2) consists of the following functions:

- Downshift switch (paddle shift) (3)
- Seek "UP" (4)
- Preset (5)
- Seek "DOWN" (6)

For information on the operation of the remote radio and paddle shift switches . With Paddle Shift
