Rear Upper Control Arm - Removal

REMOVAL





1. Raise and support the rear axle.
2. Remove the upper control arm bolt (3) and flag nut (4) at the axle (5).
3. Remove the upper control arm bolt and flag nut at the frame side (1).
4. Remove the upper control arm (2) from the vehicle.
