Shaft Coupling

REMOVAL





1. Disconnect the negative battery cable.
2. Lock the steering wheel with the tire in the straight position.
3. Remove and discard the upper pinch bolt (2) from the upper coupling at the column (1).
4. Lower the steering coupler shaft (3) from the column (1).
5. Remove the toe plate (5) nuts (4).





6. Remove and discard the midpoint pinch bolt (3) from the lower steering coupling shaft (1) at the steering gear.





7. Remove the steering coupling shaft from the vehicle.
