Special Tools

WARNING: This page is about a different car, the 2004 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Spanner Wrench - 6958

G03512055

Courtesy of DAIMLERCHRYSLER CORP.

Fig 2: Identifying Adapter Pins 8346

G03512056

Courtesy of DAIMLERCHRYSLER CORP.

Fig 3: Identifying Front Crankshaft Seal Remover 8511

G03512057

Courtesy of DAIMLERCHRYSLER CORP.

Fig 4: Identifying Front Crankshaft Seal Installer 8348

G03512058

Courtesy of DAIMLERCHRYSLER CORP.

Fig 5: Identifying HANDLE C-4171

G03512059

Courtesy of DAIMLERCHRYSLER CORP.

Fig 6: Identifying Rear Crankshaft Seal Installer 8349

G03512060

Courtesy of DAIMLERCHRYSLER CORP.

Fig 7: Identifying Rear Crankshaft Seal Remover 8506

G03512061

Courtesy of DAIMLERCHRYSLER CORP.

Fig 8: Identifying Connecting Rod Guides 8507

G03512062

Courtesy of DAIMLERCHRYSLER CORP.

Fig 9: Identifying Crankshaft Damper Installer 8512

G03512063

Courtesy of DAIMLERCHRYSLER CORP.

Fig 10: Identifying Puller 1026

G03512064

Courtesy of DAIMLERCHRYSLER CORP.

Fig 11: Identifying Crankshaft Damper Removal Insert 8513 - A

G03512065

Courtesy of DAIMLERCHRYSLER CORP.

Fig 12: Identifying Chain Tensioner Wedge 8379

G03512066

Courtesy of DAIMLERCHRYSLER CORP.

Fig 13: Chain Tensioner Pins 8514

G03512067

Courtesy of DAIMLERCHRYSLER CORP.

Fig 14: Identifying Valve Spring Compressor 8426

G03512068

Courtesy of DAIMLERCHRYSLER CORP.

Fig 15: Identifying Engine Lifting Fixture 8427

G03512069

Courtesy of DAIMLERCHRYSLER CORP.

Fig 16: Identifying Camshaft Holder 8428

G03512070

Courtesy of DAIMLERCHRYSLER CORP.

Fig 17: Identifying Holder Secondary Camshaft Chain 8429

G03512071

Courtesy of DAIMLERCHRYSLER CORP.

Fig 18: Identifying Remover, Rocker Arm 8516

G03512072

Courtesy of DAIMLERCHRYSLER CORP.

Fig 19: Identifying Idler Shaft Remover 8517

G03512073

Courtesy of DAIMLERCHRYSLER CORP.

Fig 20: Identifying Valve Spring Compressor Adapters 8519

G03512074

Courtesy of DAIMLERCHRYSLER CORP.

Fig 21: Identifying Installer Counter Balance Shaft 8641

G03512075

Courtesy of DAIMLERCHRYSLER CORP.

Fig 22: Identifying Valve Spring Tester C-647

G03512076

Courtesy of DAIMLERCHRYSLER CORP.

Fig 23: Identifying Dial Indicator C-3339

G03512077

Courtesy of DAIMLERCHRYSLER CORP.

Fig 24: Identifying Valve Spring Compressor C-3422-B

G03512078

Courtesy of DAIMLERCHRYSLER CORP.

Fig 25: Indicator, Cylinder Bore C-119

G03512079

Courtesy of DAIMLERCHRYSLER CORP.

Fig 26: Identifying Oil Pressure Gauge C-3292

G03512080

Courtesy of DAIMLERCHRYSLER CORP.

Fig 27: Identifying Piston Ring Compressor C-385

G03512081

Courtesy of DAIMLERCHRYSLER CORP.

Fig 28: Identifying Pressure Tester Kit 7700

G03512082

Courtesy of DAIMLERCHRYSLER CORP.

Fig 29: Identifying Bloc-Chek-Kit C-3685-A

G03512083

Courtesy of DAIMLERCHRYSLER CORP.

Fig 30: Identifying Engine Support Fixture 8534

G03512084

Courtesy of DAIMLERCHRYSLER CORP.
