Radiator Fan - Electric: Description
WARNING: This page is about a different car, the 2004 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
The fan ( Fig 1) is electrically controlled by the powertrain control module (PCM) through the fan control relay. This relay is located in the power distribution center (PDC) ( Fig 2). For the location of the relay within the PDC, refer to label on PDC cover.
Courtesy of DAIMLERCHRYSLER CORP.
Courtesy of DAIMLERCHRYSLER CORP.
