Symptom: *ALL DOORS FAIL TO LOCK FROM ANY SWITCH

WARNING: This page is about a different car, the 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.

POSSIBLE CAUSES

DOOR LOCK RELAY OUTPUT CIRCUIT SHORT TO GROUND

KEY-IN IGNITION SWITCH SHORTED

KEY-IN IGNITION SWITCH SENSE CIRCUIT SHORT TO GROUND

CENTRAL TIMER MODULE - DOOR LOCK OPEN

CENTRAL TIMER MODULE - KEY-IN IGNITION SWITCH SHORTED

Fig 1: *All Doors Fail To Lock From Any Switch Diagnostic Procedure (1 Of 2)

Courtesy of DAIMLERCHRYSLER CORP.

Fig 2: *All Doors Fail To Lock From Any Switch Diagnostic Procedure (2 Of 2)

Courtesy of DAIMLERCHRYSLER CORP.
