When Monitored and Set Condition: PCI FAILURE

WARNING: This page is about a different car, the 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.

When Monitored: When the DRBIII® performs the PCI Amplifier Test.

Set Condition: When the Amplifier detects a fault with the PCI circuitry.

POSSIBLE CAUSES

AMPLIFIER

INTERMITTENT CONDITION

Fig 1: PCI Failure Diagnostic Procedure
G02687543Courtesy of DAIMLERCHRYSLER CORP.
