Removal-Center Armrest Upper Inertia Latch Cover

WARNING: This page is about a different car, the 2004 Dodge Dakota and 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
  1. Move the drivers seat position to full forward with seat back full forward.
  2. Place center arm rest in the down position.
  3. Remove the screw securing the cover to the inertia latch (Figure ).
  4. Remove the upper and lower inertia latch covers.
