Transfer Case Skid Plate: Removal

WARNING: This page is about a different car, the 2004 Dodge Dakota and 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front skid plate. (Refer to FRAME & BUMPERS/FRAME/FRONT SKID PLATE - REMOVAL  )
  2. Remove the rear bolts and remove the skid plate (Fig 1 ).
    Fig 1: Removing Rear Bolts And Skid Plate
    G02657250Courtesy of DAIMLERCHRYSLER CORP.
