Cylinder Head: Description

WARNING: This page is about a different car, the 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.

The cast iron cylinder heads (Fig 1) are mounted to the cylinder block using ten bolts. The spark plugs are located in the peak of the wedge between the valves.

Fig 1: Identifying Cylinder Head Assembly-V-8 Gas Engines
G02657137Courtesy of DAIMLERCHRYSLER CORP.
