Removal-Camshaft Bearings

WARNING: This page is about a different car, the 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: This procedure requires that the engine is removed from the vehicle.
  1. With engine completely disassembled, drive out rear cam bearing core plug.
  2. Install proper size adapters and horseshoe washers (part of Camshaft Bearing Remover/Installer Tool C-3132-A) at back of each bearing shell. Drive out bearing shells (Fig 1).
    Fig 1: Removing Camshaft Bearings
    G02657152Courtesy of DAIMLERCHRYSLER CORP.
