Wiper Relay: Installation

WARNING: This page is about a different car, the 2003 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
  1. See the fuse and relay layout label affixed to the underside of the PDC cover for the proper wiper relay location (Figure ).
  2. Position the wiper relay in the proper receptacle in the PDC.
  3. Align the wiper relay terminals with the terminal cavities in the PDC receptacle.
  4. Push firmly and evenly on the top of the wiper relay until the terminals are fully seated in the terminal cavities in the PDC receptacle.
  5. Reinstall the cover onto the PDC.
