Pcm & Pcm Connector Locations

WARNING: This page is about a different car, the 2004 Chrysler Intrepid, 2003 Dodge Intrepid, 2003 Chrysler Intrepid, 2003 Chrysler Concorde, and 2003 Chrysler 300M. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Locating PCM & Identifying PCM Connectors
G00209134Courtesy of CHRYSLER CORP.
