Caravan, Mini Ram Van & Voyager

  1. Remove headlight and switch plate trim bezel. Remove switch plate-to-lower panel retaining screws. Move assembly rearward and disconnect wiring connectors. See Figure.
  2. Remove knob and stem by depressing button on switch. Remove 2 screws attaching headlight switch plate to switch plate assembly. Remove headlight switch retainer and remove switch. To install, reverse removal procedure.
