Switch-Parking Brake (D2269A)

Harness-Family: Unibody

Color: NATURAL

Gender: FEMALE

Part Number: 04400466

Part Description: Not Available

Connector No: D2269A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Switch-Parking Brake Connector End View

GCWD1024720

Courtesy of CHRYSLER

Fig 2: Switch-Parking Brake Component Location

GCWD1205881

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

B25

DG/WT

20

PARK BRAKE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
