Switch-Hood Ajar (D2245)

Harness-Family: Front_End_Module

Color: BLACK

Gender: FEMALE

Part Number: 04801212AA

Part Description: INS ASSY

Connector No: D2245

Option: ~~

Repair Kit Part Number: 05017129AA

Cavity Count: 2

Fig 1: Switch-Hood Ajar Connector End View

GCWD1025385

Courtesy of CHRYSLER

Fig 2: Switch-Hood Ajar Component Location

GCWD1205898

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

G70

VT/LB

20

HOOD AJAR SWITCH SENSE

N/A

2

Z920

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
