Starter (D6637C)

Harness-Family: Engine

Color: ~~

Gender: FEMALE

Part Number: 7003-6065-02

Part Description: STARTER TERMINAL(TIN)

Connector No: D6637C

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Starter Connector End View

GCWD1024358

Courtesy of CHRYSLER

Fig 2: Starter Component Location

GCWD1206000

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A802

DG

10

B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
