Speaker-Left Front Door (D5908)

Harness-Family: Door_Driver

Color: WHITE

Gender: FEMALE

Part Number: 174921-1

Part Description: 070 SERIES MULTILOCK CONNECTOR PLUG HSG

Connector No: D5908

Option: ~~

Repair Kit Part Number: 68040489AA

Cavity Count: 3

Fig 1: Speaker-Left Front Door Connector End View

Courtesy of CHRYSLER

Fig 2: Speaker-Left Front Door Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X291

GY/YL

LEFT FRONT SPEAKER (-)

N/A

X201

GY/VT

LEFT FRONT SPEAKER (+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
