Solenoid-Oil Pump (D2555A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 872-857-501

Part Description: MLK CONNECTOR

Connector No: D2555A

Option: ~~

Repair Kit Part Number: 68137868AA

Cavity Count: 2

Fig 1: Solenoid-Oil Pump Connector End View

GCWD1006501

Courtesy of CHRYSLER

Fig 2: Solenoid-Oil Pump Component Location

GCWD1205953

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

G62

VT/YL

20

OIL PRESSURE SOL CONTROL

N/A

2

Z901

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
