S371 (S510)

Harness-Family: Door_Pass

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S510

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S371 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S371 Component Location

GCWD1205777

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A937

RD

14

FUSED B(+)

N/A

2

A937

RD

14

FUSED B(+)

N/A

3

A937

RD

14

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
