S343 (S1412)

Harness-Family: Headliner

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S1412

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S343 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S343 Component Location

GCWD1205890

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

M27

YL/DB

20

READING LAMPS DRIVER

N/A

2

M27

YL/DB

20

READING LAMPS DRIVER

N/A

3

M27

YL/DB

20

READING LAMPS DRIVER

N/A

4

M27

YL/DB

20

READING LAMPS DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
