S339 (S390)

Harness-Family: Console_Center

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S390

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S339 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S339 Component Location

GCWD1206099

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z907

BK

14

GROUND

N/A

2

Z907

BK

18

GROUND

N/A

3

Z907

BK

20

GROUND

N/A

4

Z907

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
