S325 (S125)

Harness-Family: Unibody

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S125

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S325 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S325 Component Location

GCWD1205723

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

M27

YL/LB

22

READING LAMPS DRIVER

N/A

2

M27

YL/LB

22

READING LAMPS DRIVER

N/A

3

M27

YL/LB

22

READING LAMPS DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
