S318 (S118)

Harness-Family: Unibody

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S118

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S318 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S318 Component Location

GCWD1206147

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

L217

WT/VT

22

PARK LAMP FEED

N/A

2

L217

WT/VT

20

PARK LAMP FEED

N/A

3

L217

WT/VT

20

PARK LAMP FEED

N/A

4

L217

WT/VT

20

PARK LAMP FEED

N/A

5

L217

WT/VT

20

PARK LAMP FEED

N/A

⁽¹⁾	Pins not listed are not used for this connector
