S250 (S1650)

Harness-Family: IP

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S1650

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S250 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S250 Component Location

GCWD1205989

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X201

GY/VT

18

LEFT FRONT SPEAKER (+)

N/A

2

X201

GY/VT

18

LEFT FRONT SPEAKER (+)

N/A

3

X201

GY/VT

18

LEFT FRONT SPEAKER (+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
