S222 (S1622)

Harness-Family: IP

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S1622

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S222 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S222 Component Location
GCWD1206017Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 F202 PK/WT 18 IGNITION RUN/START CONTROL OUTPUT N/A
1 X202 DG/VT 18 RIGHT FRONT SPEAKER (+) N/A
2 F202 PK/WT 18 IGNITION RUN/START CONTROL OUTPUT N/A
2 X202 DG/VT 18 RIGHT FRONT SPEAKER (+) N/A
3 F202 PK/WT 20 IGNITION RUN/START CONTROL OUTPUT N/A
3 X202 DG/VT 18 RIGHT FRONT SPEAKER (+) N/A
4 F202 PK/WT 20 IGNITION RUN/START CONTROL OUTPUT N/A
5 F202 PK/WT 18 IGNITION RUN/START CONTROL OUTPUT N/A
(1) Pins not listed are not used for this connector
