S212 (S1612)

Harness-Family: IP

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S1612

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S212 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S212 Component Location

GCWD1205806

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

A417

RD/DB

22

FUSED B(+)

N/A

2

A417

RD/DB

22

FUSED B(+)

N/A

3

A417

RD/DB

20

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
