S102 (S1300)

Harness-Family: HDLP_Dash

Color: ~~

Gender: MALE

Part Number: NA

Part Description: Not Available

Connector No: S1300

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S102 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: S102 Component Location

GCWD1205762

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

2

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

3

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

4

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

5

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

6

T16

YL/OR

16

TRANSMISSION CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
