Radio C9 (D3843I)

Harness-Family: USB_CABLE

Color: GRAY

Gender: MALE

Part Number: ~~

Part Description: Not Available

Connector No: D3843I

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Radio C9 Connector End View

GCWD1024718

Courtesy of CHRYSLER

Fig 2: Radio C9 Component Location

GCWD1205922

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

X442

NA

22

UCI USB POWER

N/A

2

X445

NA

22

UCI USB DATA (-)

N/A

3

X444

NA

22

UCI USB DATA (+)

N/A

5

X443

NA

22

UCI USB GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
