Radio C1 (Integral HFM) (D3843A)

Harness-Family: IP

Color: GRAY

Gender: FEMALE

Part Number: 638207-6

Part Description: INSULATOR

Connector No: D3843A

Option: INTEGRAL HFM

Repair Kit Part Number: 05135638AA

Cavity Count: 10

Fig 1: Radio C1 Connector End View (Integral HFM)

GCWD1024704

Courtesy of CHRYSLER

Fig 2: Radio C1 Component Location (Integral HFM)

GCWD1206096

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

A1

X722

LB/DG

20

MICROPHONE 2 IN (+)

N/A

A2

X712

DG/LB

20

MICROPHONE 1 IN (+)

N/A

A4

X793

DG/YL

22

MICROPHONE FEED

N/A

A7

X792

LB/TN

22

MICROPHONE IN (-)

N/A

A8

X835

OR/GY

22

SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
