Pump-Vacuum (D6709A)

Harness-Family: Engine

Color: DARK GRAY

Gender: MALE

Part Number: 7282-5575-10

Part Description: 2.8 INSULATOR

Connector No: D6709A

Option: ~~

Repair Kit Part Number: 68148106AA

Cavity Count: 2

Fig 1: Pump-Vacuum Connector End View

GCWD1006564

Courtesy of CHRYSLER

Fig 2: Pump-Vacuum Component Location

GCWD1205978

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

T109

DG/GY

14

VACUUM PUMP RELAY CONTACT CONTROL

N/A

2

Z921

BK

14

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
