Motor-Seat Adjuster-Passenger Horizontal (D3025)

Harness-Family: Seat_Pass

Color: BLUE

Gender: FEMALE

Part Number: 1379217-7

Part Description: MQS 3W + MPQ 2W SOCKET HOUSING

Connector No: D3025

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 5

Fig 1: Motor-Seat Adjuster-Passenger Horizontal Connector End View

Courtesy of CHRYSLER

Fig 2: Motor-Seat Adjuster-Passenger Horizontal Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P14

LG/WT

PASSENGER SEAT HORIZONTAL FORWARD DRIVER

N/A

P15

LG/WT

DRIVER SEAT HORIZONTAL FORWARD DRIVER

N/A

P16

LG/DG

PASSENGER SEAT HORIZONTAL REARWARD DRIVER

N/A

P17

LG/DG

DRIVER SEAT HORIZONTAL REARWARD DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
