Motor-Seat Adjuster-Driver Recliner (D3028)

Harness-Family: Seat_Bag_Driver

Color: GRAY

Gender: FEMALE

Part Number: 1326490-3

Part Description: 4P RECEPTACLE HOUSING - 2X JPT + 2X MT3

Connector No: D3028

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Motor-Seat Adjuster-Driver Recliner Connector End View

Courtesy of CHRYSLER

Fig 2: Motor-Seat Adjuster-Driver Recliner Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P41

LG/GY

DRIVER RECLINER DOWN SWITCH SENSE

N/A

P43

LG/VT

DRIVER SEAT RECLINER UP DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
