Lamp-Center Bezel (D4506)

Harness-Family: IP

Color: LIGHT GRAY

Gender: MALE

Part Number: 7283-6443-40

Part Description: 2P KAIZEN YESC 1.5MM Female SUB ASSEMBLY

Connector No: D4506

Option: ~~

Repair Kit Part Number: 68065023AA

Cavity Count: 2

Fig 1: Lamp-Center Bezel Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Center Bezel Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

E12

OR/GY

PANEL LAMPS DRIVER

N/A

Z912

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
