Lamp-Assembly-Right Front C3 (Premium) (D6606C)

Harness-Family: Front_End_Module

Color: BLACK

Gender: FEMALE

Part Number: 7287-0954-30

Part Description: YESC RP TOP LOCK LIGHTING CONN W/ CPA

Connector No: D6606C

Option: PREMIUM

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Lamp-Assembly-Right Front C3 Connector End View (Premium)

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly-Right Front C3 Component Location (Premium)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L60

WT/BR

RIGHT FRONT TURN LAMP DRIVER

N/A

Z920

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
