Lamp-Assembly Tail-Right C1 (D6642A)

Harness-Family: Unibody

Color: BLACK

Gender: FEMALE

Part Number: 15326815

Part Description: TAXI ASM CONNECTORF GT 150 SLD

Connector No: D6642A

Option: ~~

Repair Kit Part Number: 68045319AA

Cavity Count: 4

Fig 1: Lamp-Assembly Tail-Right C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Lamp-Assembly Tail-Right C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z917

GROUND

N/A

L217

WT/VT

PARK LAMP FEED

N/A

L54

WT/LG

RIGHT STOP LAMP DRIVER

N/A

L62

WT/YL

RIGHT REAR TURN LAMP DRIVER

EXCEPT EXPORT

⁽¹⁾	Pins not listed are not used for this connector
